Vision system CCD camera screen printing machine

Vision system CCD camera screen printing machine
Vision system CCD camera screen printing machine

Large Image :  Vision system CCD camera screen printing machine

Product Details:
Place of Origin: Shanghai, China
Brand Name: Hoting
Model Number: PAL-1515/PAL-5040
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Packaging Details: Solid wooden box
Delivery Time: 30 days
Payment Terms: L/C, T/T, Western Union, MoneyGram, D/P
Supply Ability: 10 pieces per Month
Contact Now

Vision system CCD camera screen printing machine

Description
Operation: CCD Camera

Application scope:

This series is applicable to mobile phone panels, membrane switch, liquid crystal display board, ceramic color paper, metal plates, paper etc printing



Specification:
1. Using vision system CCD camera of high precision automatic screen printing machine
2. Vision system settings easily
3. Even a beginner can operate the machine
4. Using special software
5. Use industry reinforce the durability of the CPU


Optional:
Touch screen panel



Parameter:

Model PAL-1515 PAL-5040
Max printing size 150 X 150mm 500 X 400mm
Max frame size (OD) 320 X 320mm 750 X 550mm
Printing speed 350 Sheet/H 300 Sheet/H
Scraper running A.C Servo Motor
Printing pressure 0 ~ 50kgf 0 ~ 60kgf
Scraper angle 60° ~ 90°
Printing pressure adjust height 0 ~ 20mm
Printing table size 230 X 230mm
Table adjust X,Y:÷3mm, ┵:÷4μm
Printing table movement A.C Servo Motor
Printing table arrangement Stepping Motor
Vision system precision ÷5μm(x,y,┵) ÷10μm(x,y,┵)
Camera 2Set
Camera light LED Lamp
Photographer location area 6 X 6mm
Frame washing Film or Bucket (Option)
Printing material thickness 0.2 ~ 10mm
Printing material fixed Vacuum table
Scraper speed 50 ~ 250mm/sec 50 ~ 400mm/sec
Dimension 1970 X 1000 X 1700mm 1980 X 1130 X 1800mm
Weight Approx. 850kg Approx. 950kg
★ Special specification can be made for customized size
