Box type screen drying cabinet, screen frame dryer, screen printing frame dryer, box dry oven, screen printing drying

Box type screen drying cabinet, screen frame dryer, screen printing frame dryer, box dry oven, screen printing drying
Box type screen drying cabinet, screen frame dryer, screen printing frame dryer, box dry oven, screen printing drying Box type screen drying cabinet, screen frame dryer, screen printing frame dryer, box dry oven, screen printing drying Box type screen drying cabinet, screen frame dryer, screen printing frame dryer, box dry oven, screen printing drying Box type screen drying cabinet, screen frame dryer, screen printing frame dryer, box dry oven, screen printing drying Box type screen drying cabinet, screen frame dryer, screen printing frame dryer, box dry oven, screen printing drying Box type screen drying cabinet, screen frame dryer, screen printing frame dryer, box dry oven, screen printing drying

Large Image :  Box type screen drying cabinet, screen frame dryer, screen printing frame dryer, box dry oven, screen printing drying

Product Details:
Place of Origin: Shanghai, China
Brand Name: Hoting
Certification: ISO9001, SGS
Model Number: DFV-1210
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD FOB EXW CIF CFR Shanghai
Packaging Details: Solid export box
Delivery Time: 10-20days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10 set per month
Contact Now

Box type screen drying cabinet, screen frame dryer, screen printing frame dryer, box dry oven, screen printing drying

Description
Used For: Large Format Screen Drying

Application Scope:

The series is suitable for drying stencil in plate making process, rinsing, emulsion coating and after screen washing etc.



Features:

1. PID temperature control allows constant temperature distribution

2. Down-to-up circulation of hot air maintains constant temperature distribution

3. Stainless material prevents internal corrosion and allows long durability

4. Has a container at the bottom part, easy to clean



Parameters:

Model DFV-1210
Max frame size 1200x1000 mm
Mix frame size 200x200 mm
Partition quantity 10 space
Screen quantity 10EA
Drying method Hot air circulation
Heater Heating tube
Temperature control P.I.D
Temperature range Room -80℃
Power 7.5 KW
Electric source 380V X 3ph X 8 KW
Dimension L1213 X W1440 X H1815mm
★ Can be customized for clients frame size
